Basic Info.
Model NO.
201/304/304L/321/316/316L/317L/347H/309S/310S/904L
Steel Grade
Q195/Q235/SAE1006/SAE1008
Type
Hot Rolled
Surface Treatment
Black or Galvanized
Transport Package
Standard Marine Packaging
HS Code
7312100000
Production Capacity
500000ton/Year
Product Description
| Technical Data | |||||
| Intensity level | Wire diameter | Min. tensile strength | Min. stress with 1% extension | Min. extension percentage | Min. No. of 3600 twist |
| | mm | Mpa | Mpa | % | |
| General | 1.24~2.25 | 1340 | 1170 | 3.0 | 16 |
| | 2.25~2.75 | 1310 | 1140 | 3.0 | 16 |
| | 2.75~3.00 | 1310 | 1140 | 3.5 | 16 |
| | 3.00~3.50 | 1290 | 1100 | 3.5 | 14 |
| | 3.50~4.25 | 1290 | 1100 | 4.0 | 12 |
| | 4.25~4.75 | 1290 | 1100 | 4.0 | 12 |
| | 4.75~5.50 | 1290 | 1100 | 4.0 | 12 |
| High | 1.24~2.25 | 1450 | 1310 | 2.5 | 16 |
| | 2.25~2.75 | 1410 | 1280 | 2.5 | 16 |
| | 2.75~3.00 | 1410 | 1280 | 3.0 | 16 |
| | 3.00~3.50 | 1410 | 1240 | 3.0 | 14 |
| | 3.50~4.25 | 1380 | 1170 | 3.0 | 12 |
| | 4.25~4.75 | 1380 | 1170 | 3.0 | 12 |
| | 4.75~5.50 | 1380 | 1170 | 2.0 | 12 |
| Very high | 1.24~2.25 | 1620 | 1450 | 2.0 | 14 |
| | 2.25~2.75 | 1590 | 1410 | 2.0 | 14 |
| | 2.75~3.00 | 1590 | 1410 | 2.5 | 12 |
| | 3.00~3.50 | 1550 | 1380 | 2.5 | 12 |
| | 3.50~4.25 | 1520 | 1340 | 2.5 | 10 |
| | 4.25~4.75 | 1520 | 1340 | 2.5 | 10 |
| | 4.75~5.50 | 1520 | 1270 | 2.5 | 10 |
| Stainless steel wire rope structure | ||||
| STRUCTURE 1x7 | ||||
| Product Code | Diameter (mm) | M.B.L (kn) | M.B.L (Kg) | Weight Kg/100m |
| WR02(1x7)-C | 2 | 4.11 | 440 | 2.2 |
| WR025(1x7)-C | 2.5 | 6.76 | 690 | 3.4 |
| WR03(1x7)-C | 3 | 9.81 | 1,000 | 4.9 |
| WR035(1x7)-C | 3.5 | 13.33 | 1,360 | 6.8 |
| WR04(1x7)-C | 4 | 17.46 | 1,780 | 8.8 |
| STRUCTURE 1x19 | ||||
| Product Code | Diameter (mm) | MB.L(kn) | M.B.L (Kg) | Weight Kg/100m |
| WR04(1x19)-C | 4 | 17.46 | 1,780 | 9.1 |
| WR05(1x19)-C | 5 | 25.49 | 2,600 | 14.2 |
| WR06(1x19)-C | 6 | 35.29 | 3,600 | 20.5 |
| WR07(1x19)-C | 7 | 49.02 | 5,000 | 27.9 |
| WR08(1x19)-C | 8 | 61.76 | 6,300 | 36.5 |
| WR10(1x19)-C | 10 | 98.04 | 10,000 | 57 |
| WR12(1x19)-C | 12 | 143.15 | 14,500 | 82.1 |
| STRUCTURE 7x7 | ||||
| Product Code | Diameter (mm) | M.B.L (kn) | M.B.L (Kg) | Weight Kg/100m |
| WR01(7x7) | 1 | 0.56 | 57 | 0.38 |
| WR012(7x7) | 1.2 | 1.13 | 115 | 0.5 |
| WR015(7x7) | 1.5 | 1.26 | 128 | 0.86 |
| WR018(7x7) | 1.8 | 1.82 | 186 | 1.3 |
| WR02(7x7) | 2 | 2.24 | 228 | 1.54 |
| WR025(7x7) | 2.5 | 3.49 | 356 | 2.4 |
| WR03(7x7) | 3 | 5.03 | 513 | 3.46 |
| WR04(7x7) | 4 | 8.94 | 912 | 6.14 |
| STRUCTURE 7x19 | ||||
| Product Code | Diameter (mm) | M.B.L (kn) | M.B.L (Kg) | Weight Kg/100m |
| WR05(7x19) | 5 | 13 | 1,330 | 9.3 |
| WR06(7x19) | 6 | 18.8 | 1.920 | 13.4 |
| WR07(7x19) | 7 | 25.5 | 2,600 | 18.2 |
| WR08(7x19) | 8 | 33.4 | 3,410 | 23.8 |
| WR10(7x19) | 10 | 52.1 | 5,310 | 37.2 |
| WR12(7x19) | 12 | 85.1 | 7,660 | 53.6 |
We can produce various models according to different standards of products, specifications are as follows:
Diameter: 9.3mm, 9.53mm, 11.1mm, 12.5mm, 12.7mm, 12.9mm, 15.2mm, 15.7mm, 17.8mm, 18.9mm, 21.6mm, 21.8mm
(1)Steel Strand for PC Concrete PC strand
Standard GB/T5224 pc strand:
1×7-9.5mm 11.1mm 12.7mm 15.2mm 15.7mm 17.8mm 21.6mm,
Standard ASTM416 PC strand
1×7-7.9mm 9.53mm 11.11mm 12.7mm 13.2mm 14.29mm 15.24mm 17.8mm,
Standard BS 5896 pc strand
1×7-8.0mm 9.3mm 9.6mm 11.0mm 12.5mm 12.9mm 15.2mm 15.7mm,
Standard JIS G3536 PC strand
1×7-12.7mm 15.2mm,
Standard UNE 36094 PC strand
1×7-9.3mm 13.0mm 15.2mm,
Standard KS D PC strand
1×7-9.5mm 11.1.0mm 12.7mm 15.2mm,
Standard AS/NZS4672 PC strand
9.5mm(7 wire) 12.7mm 15.2mm,
(2) Unbonded PC Strand
1x7-9.5mm 12.7mm 15.2mm 15.7mm,
(3) Prestressed Steel Wire PC wire
Plain steel wire for prestressed concrete/indented wire /spiral rib steel wire
3.0mm 4.0mm 4.8mm 5.0mm 6.0mm 6.25mm 7.0mm 8.0mm 9.0mm 10.0mm 12mm
Diameter: 9.3mm, 9.53mm, 11.1mm, 12.5mm, 12.7mm, 12.9mm, 15.2mm, 15.7mm, 17.8mm, 18.9mm, 21.6mm, 21.8mm
(1)Steel Strand for PC Concrete PC strand
Standard GB/T5224 pc strand:
1×7-9.5mm 11.1mm 12.7mm 15.2mm 15.7mm 17.8mm 21.6mm,
Standard ASTM416 PC strand
1×7-7.9mm 9.53mm 11.11mm 12.7mm 13.2mm 14.29mm 15.24mm 17.8mm,
Standard BS 5896 pc strand
1×7-8.0mm 9.3mm 9.6mm 11.0mm 12.5mm 12.9mm 15.2mm 15.7mm,
Standard JIS G3536 PC strand
1×7-12.7mm 15.2mm,
Standard UNE 36094 PC strand
1×7-9.3mm 13.0mm 15.2mm,
Standard KS D PC strand
1×7-9.5mm 11.1.0mm 12.7mm 15.2mm,
Standard AS/NZS4672 PC strand
9.5mm(7 wire) 12.7mm 15.2mm,
(2) Unbonded PC Strand
1x7-9.5mm 12.7mm 15.2mm 15.7mm,
(3) Prestressed Steel Wire PC wire
Plain steel wire for prestressed concrete/indented wire /spiral rib steel wire
3.0mm 4.0mm 4.8mm 5.0mm 6.0mm 6.25mm 7.0mm 8.0mm 9.0mm 10.0mm 12mm
1*7wire 12.5 mm 15.24mm 15.7mmprestressing pc steel strand weights
Characteris of Prestressed Concrete Strand1.high tensile strength and elongation;low relaxation value;small stress losing;excellent durable anti-fatigue performance.
2.Grade: 250K / 270K / 290K, Tensile Strength: 1770Mpa / 1860Mpa / 1960Mpa, the 1000h Relaxation is 2.0% max and the elongation is 4.0% min.
3.Categories: plain,galvanized,PE coated,epoxy resin coated, spiral ribs, indented.
4.Application of the pc strand
1. PC strand is used as cable for special bridges and maintenance of bridges.
2. PC strand is used in concrete pillars and supports for the construction of buildings, domes for nuclear power plants and reinforcement of LNG concrete tanks.
3. PC strand is used as floor and roof reinforcement for sports stadiums.
4. PC strand can be extensively used in construction materials for PC panels, high-pressure concrete water pipes, marine structures, towers and runways.
1. PC strand is used as cable for special bridges and maintenance of bridges.
2. PC strand is used in concrete pillars and supports for the construction of buildings, domes for nuclear power plants and reinforcement of LNG concrete tanks.
3. PC strand is used as floor and roof reinforcement for sports stadiums.
4. PC strand can be extensively used in construction materials for PC panels, high-pressure concrete water pipes, marine structures, towers and runways.
